| Brand Name : | ZSound |
| Model Number : | LA110 |
| Payment Terms : | L/C,D/A,T/T,Western Union |
| Delivery Time : | 5 |
| Price : | $5575-6969 |
| Parameter | Value |
|---|---|
| Frequency Range | 60 Hz - 18 kHz (±3 dB); 50 Hz - 20 kHz (-10 dB) |
| Coverage Angle | Horizontal: 100°; Vertical: 10° (adjustable) |
| Sensitivity | High Frequency (HF): 112 dB; Low Frequency (LF): 103 dB |
| Nominal Power | 350 W |
| Impedance | 16 ohms |
| Sound Pressure Level | HF: 137 dB; LF: 134 dB |
| High Frequency Section | 1x3 inch compression tweeter (可压缩高音扬声器) |
| Low Frequency Section | 1x10 inch woofer (低音扬声器) |
| Dimensions (H×W×D) | 308 mm × 580 mm × 390 mm |
| Weight | 23 kg |
| Connectors | 2 × NL4 |
| Cabinet Material | 15mm and 18mm Baltic birch plywood (波罗的海桦木胶合板) |
| Cabinet Finish | Black polyurethane coating (黑色聚氨酯涂层) |
| Protective Grille | Black, epoxy-coated and acoustically transparent foam (黑色, 带有环氧涂层和声学透明泡沫) |
| Parameter | Value |
|---|---|
| Frequency Range | 40 Hz – 200 Hz (±3 dB) 30 Hz – 320 Hz (-10 dB) |
| Coverage Angle | Omnidirectional |
| Sensitivity | 100 dB SPL (1W/1m) |
| Rated Power | 1000 W |
| Impedance | 8 ohms |
| Max Sound Pressure (SPL) | 136 dB (Peak) |
| Low-Frequency Section | 2×15-inch vented woofers |
| Cabinet Material | 15mm/18mm Baltic birch plywood |
| Cabinet Finish | Black polyurethane coating |
| Protective Grille | Black epoxy-coated, acoustically transparent fabric |
| Dimensions (H×W×D) | 680 × 580 × 790 mm |
| Weight | 60 kg |
